Beijing Vibroflotation Engineering Machinery Co., Ltd. (BVEM) started from a special R&D team worked for a vibroflot strategic localization project and organized by Ministry of Water Resources and Hydro-power. After 40 years development of products and market, BVEM has grown to be a well-known enterprises in China’s foundation engineering industry. With the main business of complete sets of equipment supplying for vibroflotation construction, BVEM was included into the group of National High & New Technology Enterprise.
vibroflotation for compacting
bvem vibro piling contractors
sand compaction vibro piling contractors
Place of Origin: CHINA
Brand Name: BVEM
Certification: ISO 9001:2015
Model Number: BJV260E-450
Product Details
Payment & Shipping Terms
Product Description:
BVEM China Vibro Piling Contractors 450mm 260kw Vibro float Machine used for Sand Compaction
| Big Power 260kW Electric Vibroflot Spec. | ||||||||
|---|---|---|---|---|---|---|---|---|
| Type | Power (kW) |
Rated current(A) | Max rotation speed(rpm) | Max amplitude (mm) |
Vibration power(kN) | Weight (kg) | Outer diameter(mm) | Length(mm) |
| BJV260E-450 | 260 | 500 | 1450 | 25 | 520 | 3280 | 450 | 3400 |
BVEM | vibroflot equipment manufacturer in China
1. The first one who introduced and studied vibro compact method in China.
2. The first one who developed application in Chinese projects.
3. Has the top experts of vibroflotation tech. and experienced construction management team.
4. China first one who reserched and produced vibrators.
5. China first and only one who produced the Bottom Feed Vibroflot.
6. The first one who produced domestic hydraulic-driven vibrator.
7. All types&models coverage:30kw-260kw.
8. Editor-in-cheif of industry standards "Technical Specification of Vibroflotation Method in Hydrauelectric and Water Resources Projects"(DL/T5214-2005).
9. Editor-in chelf of industry standrds "Electrical Deep Vibrator"(DL/T 1557-2016).
10. China first one who developed vibroflotation application in variety of industry(thermal power, hydraulic power, petrochemical, highway, rail, port etc.).
11. Cooperate with DI and support to formulate the design and construction scheme
Vibroflotataion Techniques
Vibroflotation can be obtained by using three different techniques:
Vibro Compaction method- This method allows granular soils to be compacted. This method is only used to compact sandy soils.
Vibro Replacement method- The technique is used to replace poor or inadequate soil material by flushing out the soil with air or water and replacing it with granular soil. This can be used in various soil types such as clay and sandy soils.
Vibro Displacement method- This procedure is used with no or small amounts of water used during the technique. The probe is inserted into the soil and it will displace it laterally as the new soil column is being formed and compacted.
Vibroflotation Advantages
Vibroflotation is one affordable way to improve ground conditions when a deep layer of inadequate soil is found. The technique is so simple that will not require the delivery of additional materials or additional equipment other than the probe and the equipment that has it installed.
